Yes Active Huawei Carton 1, 035 X 700 365 mm Pure Sine Wave Solar Inverter

Customization:	Available
After-sales Service:	Yes
Warranty:	5 Years

Overview - Basic Info

Model NO.SUN2000-100KTL-M2

Nature of SourceActive Inverter

PhaseThree

Output Power100kw

CertificationSAA, CE, ROHS, ISO9001, TUV CQC SAA

BrandHuawei

TypeDC/AC Inverters

Power SourceSolar Power, Wind Power

Circuit TopologiesPush-pull Type

Nature of WaveSine Wave Inverter

Weight85kg

Transport PackageCarton

Specification1,035 x 700 x 365 mm

OriginChina

HS Code8504403090

Production Capacity10000PCS Per Month

Product Description

SUN2000-100KTL-M2

Smart PV Controller

Technical Specifications

Parameter	SUN2000-100KTL-M2
Efficiency
Max. Efficiency	98.8% @480 V, 98.6% @380 V / 400 V
European Efficiency	98.6% @480 V, 98.4% @380 V / 400 V
Input
Max. Input Voltage	1,100 V
Max. Current per MPPT	26 A
Max. Short Circuit Current per MPPT	40 A
Start Voltage	200 V
MPPT Operating Voltage Range	200 V ~ 1,000 V
Number of MPP trackers	10
Max. input number per MPP tracker	2
Output
Nominal AC Active Power	100,000 W
Max. AC Apparent Power	110,000 VA
Nominal Output Voltage	480 V/ 400 V/ 380 V, 3W+(N)+PE
Rated AC Grid Frequency	50 Hz / 60 Hz
Max. Output Current	133.7 A @480 V, 160.4 A @400 V, 168.8 A @380 V
Protection
Input-side Disconnection Device	Yes
Anti-Islanding Protection	Yes
AC Overcurrent Protection	Yes
DC Reverse-Polarity Protection	Yes
PV-array String Fault Monitoring	Yes
DC/AC Surge Arrester	Type II
Arc Fault Protection	Optional
General Data
Dimensions (W x H x D)	1,035 x 700 x 365 mm
Weight (with mounting plate)	90 kg
Operating Temperature Range	-25°C ~ 60°C
Protection Degree	IP66

Product Details

Packing & Delivery

Project Show

Frequently Asked Questions

What are your main product offerings?

We provide a comprehensive range of PV solutions including Solar Panels, Solar Systems, Batteries, Inverters, and Wi-Fi RTU units.

How is product quality guaranteed?

Quality is maintained through strict processes: we always provide a pre-production sample before mass production and conduct a final inspection before every shipment.

What delivery terms do you accept?

We support various delivery terms including FOB, CFR, CIF, EXW, and DDP to accommodate different logistical requirements.

What payment methods and currencies are supported?

We accept payments in USD, EUR, and CNY. Accepted payment types include T/T, L/C, and PayPal.

Which languages can your service team communicate in?

Our professional team can communicate in multiple languages including English, Chinese, Spanish, Japanese, German, and Russian.

What is your production capacity for inverters?

We have a robust production capacity of approximately 10,000 pieces per month for our inverter range.
