Product Description

Basic Specifications

Model NO.

Principle of Work

Vector Control Transducer

Switch Mode

PWM Control

Main Circuit Type

Current

Power Supply

Low Voltage VFD

Transformation

AC-DC-AC

Function

Constant Torque Universal

Brake Unit

Built-in (Below 45kw)

Warranty

18 Months

EMC Filter

Built-in

HS Code

85044090

Capacity

5000 PCS / Month

Product Overview

General Purpose Frequency Inverter AC Drive VFD VSD

The V9 series variable frequency drive supports 1 phase 200V-240V and 3 phase 240V/415V/480V, featuring RS485 communication and an IP20 enclosure rating. This inverter is optimized for precise motor control across various industrial sectors including machine tools, chemicals, metallurgy, steel, textiles, and petroleum.

Key Features

High-clarity LED display showing frequency, voltage, and current.
IP20 protection level with forced air-cooling for thermal stability.
Versatile installation: supports both wall-mounted and floor-standing setups.
Advanced PLC and multi-speed operation modes for complex tasks.
Intuitive control panel layout for ease of use and high security.
Built-in brake units and EMC filters for steady performance.

Technical Parameters

Basics	Model	V9 series
	Control Mode	Vector control
	Color	Standard Black / Optional
	Capacity	Based on Model
I/O Features	Input Voltage	1ph 220V / 3ph 380V-480V
	Output Voltage	0 to Input voltage
	Output Frequency	0-500Hz
	Overload Capacity	150% for 60s, 180% for 3s
Control Features	Communication	RS485
	Start Torque	150% of rating torque at 1 Hz
	Accuracy	Digital: ±0.01%; Analog: ±0.2%
	AVR Function	Maintains constant output voltage

Applications & Facilities

Industrial Application

Manufacturing Facility

Global Exhibition

Quality Certificates

Packaging & Delivery

Dimension Details

Frequently Asked Questions

What is the input voltage range for the V9 series VFD?

The V9 series supports 1 phase 220V (176V-264V) and 3 phase 380V-480V (ranging from 304V up to 528V depending on specific model settings).

Does this inverter include a built-in brake unit?

Yes, models below 45kw come with a built-in brake unit. For higher power requirements, external brake resistors can be added.

What kind of control modes are supported?

The V9 series utilizes Vector Control and PWM (Pulse Width Modulation) for precise motor speed and torque regulation.

What is the overload capacity of the drive?

The drive provides an overload capacity of 150% of the rated current for 1 minute and 180% of the rated current for 3 seconds.

Can it be used in harsh industrial environments?

It has an IP20 enclosure rating and operates in temperatures from -10ºC to +40ºC. It features built-in EMC filters and forced air-cooling to ensure stability.

What communication protocols are available?

The V9 series comes standard with RS485 communication, allowing for easy integration into automated industrial systems.
